BMW XT Race Sprung 6-Pad Clutch Kit - ACT BM14-XTG6
BMW XT Race Sprung 6-Pad Clutch Kit - ACT BM14-XTG6
BM14-XTG6 kit features an Xtreme pressure plate for the most demanding driver. ACT Xtreme pressure plates use exclusive diaphragm design to increase clamp load, reduce deflection and maximize clutch life. All diaphragms endure a four-stage, heat-treating process for unparalleled performance. ACT pressure plates have precision cover stampings to provide rigidity and consistency. ACT's 6-pad spring-centered race disc features a spring-center construction to properly damp torsional vibrations and resist failure under harsh conditions. ACT spring retainers utilize wraparound spring windows and thicker retainer stampings to provide spring support, reduce stress concentrations, and increase strength and reliability. With the 6-pad spring-centered race disc, engagement is harsher, but shifting is faster. The 6-pad spring-centered disc is recommended for larger clutch sizes to absorb more heat.
Specifications | Item Description | XT/Race Sprung 6 Pad |
|---|
| Product Weight (lbs.) | 16.5 |
|---|
| Torque Capacity (ft/lbs.) | 702 |
|---|
| Torque Capacity Over OE | 129% |
|---|
| Disc Material | Ceramic |
|---|
| Clutch Disc Diameter (Inches) | 9.4 |
|---|
| Clutch Disc Diameter (Millimeters) | 240 |
|---|
| Input Shaft Diameter (inches) | 1.375 |
|---|
| Pressure Plate Type | Xtreme |
|---|
Since 1994, Advanced Clutch Technology has specialized in delivering the highest performing driveline components in the industry. A laser-guided focus on customer service, quality and reliability has earned the company a coveted reputation across all segments of the performance aftermarket. Each product offering is thoroughly researched, engineered and tested to ensure it performs up to the challenge of customer expectations - with the goal of far exceeding them. This all-in commitment to excellence has resulted in the support of numerous victories and championships around the world. These same standards also ensure street products provide the solid performance relied upon day after day. Where 90-120 day warranties are the norm, ACTs 1-year limited warranty signifies this promise so enthusiasts know they are making the preferred choice.
Warranty Information
ACT warrants all products to be free of defects in materials and workmanship for normal use and service for a period of one (1) year from retail purchase. Written notice must be immediately given to ACT within the warranty period. We require a copy of the purchase receipt showing the unit was purchased from an Authorized Dealer to verify the product is under warranty. Products purchased used do not carry a warranty. This warranty is to the original purchaser and is non-transferable. All non-warranty items are subject to a (fifty) $50 inspection bench test fee. ACT reserves the right to examine any part returned for warranty claim to determine, to ACT’s satisfaction, whether the material or workmanship of the part does not conform to this limited warranty. ACT’s obligation under this warranty shall be limited to repairing, replacing, or crediting, at its option, any part which is deemed covered by ACT. No labor, lift or storage charges will be reimbursed for any reason. Damage to ACT’s parts resulting from misuse, improper use, or abuse shall void this limited warranty. Failure to follow ACT’s installation instructions and the vehicle manufacturer’s installation procedures and specifications shall void this limited warranty. ACT undertakes no responsibility for the quality of the goods except as otherwise provided in this contract. ACT assumes no responsibility that the goods will be fit for any particular purpose for which you may be buying these goods, except as otherwise provided in the contract. ACT shall not be liable for any damage or injury to persons or property resulting from improper installation or misuse of any part subject to this warranty.
